Adjustable Ground Screw pile
  • MG Solar
  • Fujian, China
  • Within 7 days
  • 20,000 pcs/Day
  • 1PC
  • US $ 12.8~13.4/PCS

It can be installed and removed efficiently and can be installed in different locations. Suitable for all terrain, including hillsides and soil types. Not only is it durable and long lasting it is also easy to disassemble and reusable.

Adjustable Ground Screw pile

Ground Screw


Product Description

Technical Parameters

Material: Hot-galvanized Steel Q235

High Class Hot-galvanized 80u~120u

It can be efficiently installed and removed and can be installed in a variety of locations. Suitable for all terrain, including hillsides and soil types. It is not only durable, but also easy to disassemble and reusable.


Product details display

Screw Pile

Ground Mounting
 Ground Screw


Item No.DiameterThicknessLength
MG-AGS-F76-T3.0-L160076mm
3mm
1600mm
MG-AGS-F76-T3.0-L18001800mm
MG-AGS-F76-T3.0-L20002000mm
MG-AGS-F76-T3.0-L22002200mm
MG-AGS-F76-T3.0-L25002500mm
MG-AGS-F76-T3.0-L30003000mm


Packaging & Shipping

Packaging Details

Cartons, wooden or metal pallets.

Delivery Time

within 10 days after receiving 30% deposit


SGS Test Report

Screw PileGround MountingGround Screw


Payment Terms Details

Payment TermsT/T
EXW
30% as deposit, the balance before shipment
FOB
CIF
DDP/DDU


Free Design

Screw Pile


Past Related Projects Reference

Ground Mounting


Related Products

Ground Screw


FAQ

Q: What’s the material of the ground screw pile?

MG SOLAR:Hot-Dipped Galvanized Steel Q235(HDG Q235B)


Q: What’s the thickness of the galvanized coating?

MG SOLAR:80μm~120μm. Determined by the material thickness



Q: What’s the diameter of the screw pile?

MG SOLAR:76mm, 89mm, 114mm are available for options. 76mm is the common use.



Q: What’s the thickness of screw pile material?

MG SOLAR:2.5mm~4mm, 3mm is the common use.



Q: What is the total length range of adjustable screw piles?

MG SOLAR:1600mm~1900mm



Q: How to choose the screw pile?

MG SOLAR:Based on soil condition and project load to choose correct thickness and diameter of screw pile.



Q: What is the length of screw pile you can offer?

MG SOLAR:Common use is 1600mm,1800mm,2000mm,we can offer between 1000mm to 3000mm.



Q: What kind of systems can screw pile be used for?

MG SOLAR:It can be used for ground mount systems, solar farm structure systems and carport structure systems.




Please feel free to contact us, if there is anything we can do for you !
